PC60QL03N

Features: · Dual-Cathode Common to Base Plate · Extremely Low Forward Voltage Drop · Low Power Loss, High Efficiency · High Surge Capability · UL Recognized, File No. E187184 Application·High Frequency Rectification Specifications Paeameter Symbol PC60QL03N Unit Repetitive Peak Reverse...

product image

PC60QL03N Picture
See larger image
SeekIC No. : 004456007 Detail

PC60QL03N: Features: · Dual-Cathode Common to Base Plate · Extremely Low Forward Voltage Drop · Low Power Loss, High Efficiency · High Surge Capability · UL Recognized, File No. E187184 Application·High Freque...

PC60QL03N Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
PC60QL03N
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/29

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Dual-Cathode Common to Base Plate
· Extremely Low Forward Voltage Drop
· Low Power Loss, High Efficiency
· High Surge Capability
· UL Recognized, File No. E187184


Application

·High Frequency Rectification


Specifications

Paeameter Symbol PC60QL03N Unit
Repetitive Peak Reverse Voltage per Arm VRRM 30 V
Repetitive Peak Surge Reverse Voltage VRRSM 35 (Pulse Width 1 sec, Duty 1/50) V
Electrical Rating   Conition Rating
Average Rectified Output Current IO 50Hz Half Sine Wave condition
per Arm Tc=87°C 		60 A
RMS Forward Current IF(RMS) per Arm 94 A
Surge Forward Current IFSM 50 Hz Half Sine Wave,1cycle
Non-repetitive per Arm 		800 A
Operating JunctionTemperature Range Tjw   -40 to +150 °C
Storage Temperature Range Tstg   -40 to +150 °C
Mounting torque Ftor Case mounting(recommended) 1.45 N.m
Terminal Screw(recommended) 1.45
