PC80QL02N

PC80QL02N is a type of schottky barrier diode module which has four unique features: the first one is dual-cathode common to base plate. The second one is extremly low forward voltage drop. The third one is low power loss, high efficiency. The forth one is high surge capability.

There are some maximum ratings about PC80QL02N. Repetitive peak reverse voltage per Arm(VRRM) is  20 V. Repetitive peak surge reverse voltage per Arm(pulse width 1 usec,duty 1/50)(VRRSM) is 25 V. Electrical ratings: Average retified output current per Arm(Io) is 89 A(180°rectangular wave conduction per Arm , Tc is 93) .Peak one-cycle forward surge current per Arm(IFSM) is 1600 A (50 Hz half sine wave, non-repetitive). Operating junction temperature range is -40 to +125.Storage temperature range is -40 to +125. Electricla and thermal characteristics: Peak forward voltage(VFM) is 0.46 V max when IFM is 80 A, Tj is 25 per Arm. Peak reverse current(IRM) is 160 mA max when VRM is VRRM, and Tj is 25 per Arm. Thermal resistance is 0.46/W(junction to case per Arm) or is 0.12/W(case to fin).
