Purchase PC852, In-stock PC852 From SeekIC.

MFG:SHARP  Package Cooled:DIP-4  D/C:00+

PC852 Product Image

PC8 Series Datasheet download

Five Points

Part Number: PC852



MFG: SHARP

Package Cooled: DIP-4

D/C: 00+



Urgent Purchase

PC852 Maximum Ratings

Parameter
Symbol
Rating
Unit
PC852 Series
PC853P   C853H
Input
Forward current
IF
50
50
mA
*1Peak forward current
I FM
1
1
A
Reverse voltage
VR
6
6
V
Power dissipation
P
70
70
mW
Output
Collector-emitter voltage
VCEO
300
300      350
V
Emitter-collector voltage
VECO
0.1
0.1
V
Collector current
IC
150
150
mA
Collector power dissipation
PC
150
300
mW
Total power dissipation
P tot
200
320
mW
*2 Isolation voltage
Viso
5 000
5 000
Vrms
Operating temperature
T opr
- 30 to + 100
- 30 to + 100
°C
Storage temperature
T stg
- 55 to + 125
- 55 to + 125
°C
*3Soldering temperature
T sol
260
260
°C
*1 Pulse width<=100 m s, Duty ratio : 0.001
*2 40 to 60% RH, AC for 1 minute
*3 For 10 seconds

PC852 Features

· High collector-emitter voltage PC852 Series , PC853 ( VCEO : 300V) PC853H (VCEO : 350V)
· High current transfer ratio ( CTR: MIN. 1 000% at IF = 1mA, VCE= 2V)
· High isolation voltage between input and output (Viso:5 000V rms )
· Compact dual-in-line package PC852, PC853, PC853H ( 1-channel type )PC8D52 (2-channel type PC8Q52 (4-channel type )
· Large collector power dissipation. PC853, PC853H (PC : 300mW)
· Recognized by UL ( NO. E64380 )

PC852 Typical Application

· Telephone sets
· Copiers, facsimiles
· Interface with various power supply circuits, power distribution boards
· Numerical control machines
