PC97307

The PC87307/PC97307 (VUL) are functionally identical parts that offer a single-chip solution to the most commonly used ISA, EISA and MicroChannel® peripherals. PC97307 fully Plug and Play (PnP) compatible chip incorporates a Floppy Disk Controller (FDC), a Keyboard and mouse Controller (KBC), a Real-Time Clock (RTC), two fast full function UARTs, Infrared (IR) support, a full IEEE 1284 parallel port, three general purpose chip select signals that can be programmed
for game port control, and a separate configuration register set for each module. PC97307 also provides support for power management (including a WATCHDOG timer) and standard PC-AT address decoding for on-chip functions. The Plug and Play (PnP) support in PC97307 conforms to the "Plug and Play ISA Specification" Version 1.0a, May 5, 1994.

The Infrared (IR) interface complies with the IrDA 1.0 SIR and SHARP-IR standards, and supports all four basic protocols of PC97307 for Consumer-IR (TV-Remote) circuitry (RC-5, RC-5 extended, RECS80 and NEC).
