Purchase PCT1789W, In-stock PCT1789W From SeekIC.
Part Number: PCT1789W
Description: The PCT789T-A device provides the interface and buffering between PCI bus and CODEC serial interface, ...
- Table of contents:
PCT1789W
-
Suppliers
DataSheet
General Description
PCT1789W General Description
The PCT789T-A device provides the interface and buffering between PCI bus and CODEC serial interface, input/output port, interrupt control, and auto power-down management. This device works with CODEC, DAA, and PC-TEL's advanced host signal processing software to perform data/fax/voice functions. The figure below shows the hardware block diagram of an internal modem using the PCT789T-A device.
PCT789T-A is a single-chip modem controller which supports PC-TEL Host Signal Processing 56Kbps modem solution. The PCT789T-A provides the mostcompact, power-saving, and cost-effective solution for 56Kbps internal modems. It can also be used with other hardware such as audio chip and video-conferencing chip sets for combo board applications.
PCT1789W Maximum Ratings
| PARAMETER | SYMBOL | VALUE | UNIT |
| DC supply voltage | VDD | 0.3, 7.0 | V |
| Digital input voltage | VI, VIN | 0.3, VDD+0.3 | V |
| Digital input current | II, IIN | ±1 | mA |
| Operating temperature | TOPER | 0, 70 | °C |
| Storage temperature | TSTG | 40, 125 | °C |
| Maximum power dissipation | PDMAX | 200 | mW |
| Electrostatic discharge | ESD | 2000 | V |
PCT1789W Features
• 3.3 V PCI HSP Controller
• 56K ITU upgradable/data 14.4K Fax/ADPCM Voice/V.80
• Low power consumption (35 mW operating @ 3.3 V) and auto power management
• Supports Win 95, Win 98, Win NT 4.0 and NT 5.0 operating systems
• Support for D3 cold, VAUX, Wake-on-Ring
• Minimum system configuration: Pentium MMX 166 MHz +, AMD K6 MMX 200 MHz +, or Cyrix 6x86MX PR200 +; 256K Cache; 16 MB RAM
• HSP speakerphone via software upgrade with fullduplex sound chip
• V.80 for Point to Point H.324 video conferencing
• 56K ITU upgradable/data 14.4K Fax/ADPCM Voice/V.80
• Low power consumption (35 mW operating @ 3.3 V) and auto power management
• Supports Win 95, Win 98, Win NT 4.0 and NT 5.0 operating systems
• Support for D3 cold, VAUX, Wake-on-Ring
• Minimum system configuration: Pentium MMX 166 MHz +, AMD K6 MMX 200 MHz +, or Cyrix 6x86MX PR200 +; 256K Cache; 16 MB RAM
• HSP speakerphone via software upgrade with fullduplex sound chip
• V.80 for Point to Point H.324 video conferencing
PCT1789W Connection Diagram
