Part Number: PDT0313-FC-A
Description: The PDT0313-FC-A uses Hewlett-Packard's highly reliable top entry photodiode mounted in a high speed p...
- Table of contents:
PDT0313-FC-A
-
Suppliers
DataSheet
General Description
PDT0313-FC-A General Description
The PDT0313-FC-A uses Hewlett-Packard's highly reliable top entry photodiode mounted in a high speed packaging environ-ment to exploit the wide band-width performance of the PIN.
The optical interface is by means of an FC connector housing. The electrical interface is through an SMA compatible connector. The receptacle includes a standard two hole panel mounting flange.
PDT0313-FC-A Maximum Ratings
Absolute maximum limits mean that no catastrophic damage will occur if the product is subjected to these ratings for short periods, provided each limiting parameter is in isolation and all other parameters have values within the performance specification.
It should not be assumed that limiting values of more than one parameter can be applied to the product at the same time.
|
Parameter |
Minimum |
Maximum |
Units |
| Reverse Voltage |
- |
15 |
V |
| Forward Voltage |
- |
0.5 |
V |
| Forward Current |
- |
5 |
mA |
| Optical Power |
- |
5 |
mW |
| Operating Temperature |
-20 |
65 |
PDT0313-FC-A Features
· Industry Standard FC Connector
· Low Dark Current
· High Reliability Planar InGaAs PIN Photodiode
· High Responsivity
PDT0313-FC-A Typical Application
· Instrumentation
· O-E Converters
· Single and Multimode Fiber Communications Systems
· Data Communications Receivers
