Part Number: PE55FG









Description: Power Thyristor/Diode Module PK55FG series are designed for various rectifier circuits and power contr...


Urgent Purchase

PE55FG General Description


Power Thyristor/Diode Module PK55FG series are designed for various rectifier circuits and power controls. For your circuit application, following internal connections and wide voltage ratings up to 1600V are available. and electrically isolated mounting base make your mechanical design easy.

PE55FG Maximum Ratings

Symbol
Item
Ratings
Unit
PK55FG40
PD55FG40
PE55FG40
PK55FG80
PD55FG80
PE55FG80
PK55FG120
PD55FG120
PE55FG120
PK55FG160
PD55FG160
PE55FG160
VRRM *Repetitive Peak Reverse Voltage
400
800
1200
1600
V
VRSM *Non-Repetitive Peak Reverse Voltage
480
960
1300
1700
V
VDRM *Repetitive Peak off-state Voltage
400
800
1200
1600
V

Symbol
 Item

Conditions
Ratings
Unit
ITAV
 *Average On-state Current Single phase, half wave,180conduction, Tc = 81
55
A
ITRMS
 *R.M.S. On-state Current Single phase, half wave, 180conduction, Tc = 81
86
A
ITSM
 *Surge On-state Current 1/2 Cycle, 50/60HZ, Peak Value, non-repetitive
1190/1300
A
I2t
 *I2t Value for one cycle surge current
7040
A2S
PGM
 Peak Gate Power Dissipation
10
W
PG(AV)
 Average Gate Power Dissipation
1
W
IFGM
 Peak Gate Current
3
A
VFGM
 Peak Gate Voltage (Forward)
10
V
VRGM
 Peak Gate Voltage (Reverse)
5
V
di/dt
 Critical Rate of Rise of On-stateurrent IG = 100mA,VD = 1/2VDRM,diG/dt = 0.1A/s
10
A/s
VISO
 *Isolation Breakdown VoltageR.M.S A.C. 1minute
2500
V
Tj
 *Operating Junction Temperature
-40 to +125
Tstg
 *Storage Temperature
-40 to +125

Mounting
Torque
Mounting(M5)
 Recommended Value 1.5-2.515-25
2.7(28)
N.m
(kgf.cm)
Terminal(M5)
 Recommended Value 1.5-2.515-25
2.7(28)
N.m
(kgf.cm)
  Mass Typical Value
170
g

PE55FG Features

· IT(AV) 55A, IT(RMS) 86A, ITSM 1300A
· di/dt 100A/s
· dv/dt 1000V/s

PE55FG Typical Application

· Various rectifiers
· AC/DC motor drives
· Heater controls
· Light dimmers
· Static switches
