PI29FCT53T

Storage Temperature .................................................................... -65°C to +150°C
Ambient Temperature with Power Applied .....................................-40°C to +85°C
Supply Voltage to Ground Potential (Inputs & Vcc Only) .............. -0.5V to +7.0V
Supply Voltage to Ground Potential (Outputs & D/O Only) ........... -0.5V to +7.0V
DC Input Voltage ............................................................................ -0.5V to +7.0V
DC Output Current ..................................................................................... 120 mA
Power Dissipation ..........................................................................................0.5W

Note:Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductorís PI29FCT series of logic circuits are produced in the Companyís advanced 0.8 micron CMOS technology, achieving industry leading speed grades.The PI29FCT52T and the PI29FCT53T are 8-bit registered transceivers designed with two 8-bit back-to-back registers to store data flowing in both directions between two bidirectional buses. Separate clock enable and 3-state output enable signals are provided for each register. The PI29FCT52T is a non-inverting option of the PI29FCT53T.
