PI3B16224

Above which useful life may be impaired. For user guidelines, not tested.
Storage Temperature Range, TSTG ......................................... 65ºC to +150ºC
Ambient Temperature with Power Applied ..................... 40ºC to +85ºC
Supply Voltage Range, to Ground Potential .................... 0.5V to +4.6V
Input Voltage Range .......................................................... 0.5V to +4.6V
DC Output Current ......................................................................... 120mA
Power Dissipation .............................................................................0.5W
Note:
Stresses greater than those listed under MAXIMUMRATINGS may cause permanent damage to the device.This is a stress rating only and functional operation of thedevice at these or any other conditions above thoseindicated in the operational sections of this specificationis not implied. Exposure to absolute maximum ratingconditions for extended periods may affect reliability.

Pericom Semiconductor's PI3B16224 is a 3.3V, 12-bit to 24-bit mux/demux bus switch designed with a low On-Resistance allowinginputs to be connected directly to outputs.
