PJ-102A

Series: -
Manufacturer: CUI Inc
Connector Type: Jack
Gender: Male
Number of Positions/Contacts: 2 Conductors, 3 Contacts
Internal Switch(s): Single Switch, Normally Closed
Termination: Solder
Shielding: Unshielded
Features: -
Color: Black
Plug/Mating Plug Diameter: 2.1mm ID, 5.5mm OD
Mounting Type: Through Hole, Right Angle


Specifications

rating: 16 Vdc @ 2.5A

contact resistance: 30m MAX

insulation resistance: 50M MIN @ 100V DC

voltage withstand: 250V AC RMS for 1 minute

center pin diameter: 2.0 mm

input hole diameter: 6.5 mm

flammability: UL94V-0

life: 5,000 cycles

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Description

The PJ-102A is designed as one kind of center pin diameter device that has some points of specifications:(1)rating: 16V DC @ 2.5 A;(2)contat resistance: 30 m OHMS max.;(3)insulation resistance: 50 M OHMS min is 100 V DC;(5)voltage withstand: 250V AC R.M.S. for 1 minute;(6)life: 5000 cycles. If you want to know more information such as the electrical characteristics about the PJ-102A, please download the datasheet in www.seekic.com or www.chinaicmart.com.

Parameters:

Technical/Catalog Information	PJ-102A
Vendor	CUI Inc
Category	Connectors
Connector Type	Jack
Gender	Male
Plug/Mating Plug Diameter	2.1mm ID, 5.5mm OD
Signal Lines	-
Number of Positions/Contacts	2 Conductors, 3 Contacts
Mounting Type	Through Hole, Right Angle
Features	-
Color	Black
Termination	Solder
Internal Switch(s)	Single Switch, Normally Closed
Shielding	Unshielded
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	PJ 102A PJ102A CP 102A ND CP102AND CP-102A
