PM13666S-1R0M-RC

PM1 Series Datasheet download

Five Points

Part Number: PM13666S-1R0M-RC

Category: Inductors, Coils, Chokes

MFG: JW Miller A Bourns Company





Descriptions: INDUCTOR SHIELDED PWR 1.0UH SMD

Price Break

500
1000
2500

Unit Price

1.09500
1.02200
.94900

Extended Price

547.50
1022.00
2372.50

(All prices are in USD) Prices for reference only
Urgent Purchase

PM13666S-1R0M-RC General Description

INDUCTOR SHIELDED PWR 1.0UH SMD

PM13666S-1R0M-RC Parameters

Technical/Catalog InformationPM13666S-1R0M-RC
VendorJW Miller A Bourns Company
CategoryInductors, Coils, Chokes
Inductance1H
Tolerance±20%
Package / Case0.547" L x 0.531" W x 0.232" H (13.90mm x 13.50mm x 5.90mm)
PackagingTape & Reel (TR)
Type-
Current 29A
Mounting TypeSurface Mount
Q @ Freq-
Self Resonant Freq-
DC Resistance (DCR)2.500 mOhm Max
ShieldingShielded
ApplicationsPower Supplies
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names PM13666S 1R0M RC
PM13666S1R0MRC
M8499TR ND
M8499TRND
M8499TR

PM13666S-1R0M-RC datasheet

PM1+BASEPLATE
PDF/DataSheet Download
