Purchase PR2001, In-stock PR2001 From SeekIC.
- Table of contents:
PR2001
-
Suppliers
DataSheet
General Description
PR2001 Maximum Ratings
|
Characteristic |
Symbol |
PR 2001 |
PR 2002 |
PR 2003 |
PR 2004 |
PR 2005 |
Unit |
| Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage |
VRRM VRWM VR |
50 |
100 |
200 |
400 |
600 |
V |
| RMS Reverse Voltage |
VR(RMS) |
35 |
70 |
140 |
280 |
420 |
V |
| Average Rectified Output Current (Note 1) @ TA = 55 |
IO |
2.0 |
A | ||||
| Non-Repetitive Peak Forward Surge Current 8.3ms Single half sine-wave Superimposed on Rated Load (JEDEC Method) |
IFSM |
50 |
A | ||||
| Forward Voltage @ IF = 3.0A |
VFM |
1.2 |
V | ||||
| Peak Reverse Current @ TA = 25 at Rated DC Blocking Voltage @ TA = 125 |
IRM |
5.0 100 |
A | ||||
| Reverse Recovery Time (Note 3) |
trr |
150 |
250 |
ns | |||
| Typical Junction Capacitance (Note 2) |
Cj |
35 |
15 |
pF | |||
| Typical Thermal Resistance Junction to Ambient |
RJA |
50 |
K/W | ||||
| Operating and Storage Temperature Range |
Tj, TSTG |
-65 to +150 |
|||||
2. Measured at 1.0MHz and applied reverse voltage of 4.0 V DC.
3. Measured with IF = 0.5A, IR = 1.0A, Irr = 0.25A. See figure 5.
PR2001 Features
· Diffused Junction
· Fast Switching for High Efficiency
· High Current Capability and Low Forward Voltage Drop
· Surge Overload Rating to 50A Peak
· Low Reverse Leakage Current
· Plastic Material: UL Flammability Classification Rating 94V-0
· Fast Switching for High Efficiency
· High Current Capability and Low Forward Voltage Drop
· Surge Overload Rating to 50A Peak
· Low Reverse Leakage Current
· Plastic Material: UL Flammability Classification Rating 94V-0
