PRS07

Features: · Low leakage current n Glass passivated· Hermetically sealed package n Small package.Application· Switched-mode power supplies ·Snubber diode.PinoutSpecifications Symbol Parameter Conditions Min Max Unit VRRM repetitive peak reverse voltage - PRS07D - 200 V ...

product image

PRS07 Picture
See larger image
SeekIC No. : 004465331 Detail

PRS07: Features: · Low leakage current n Glass passivated· Hermetically sealed package n Small package.Application· Switched-mode power supplies ·Snubber diode.PinoutSpecifications Symbol Parameter ...

PRS07 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
PRS07
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·  Low leakage current n Glass passivated
·  Hermetically sealed package n Small package.


Application

·  Switched-mode power supplies
·  Snubber diode.


Pinout

Connection Diagram


Specifications

Symbol Parameter Conditions Min Max Unit
VRRM repetitive peak reverse voltage   -
PRS07D   - 200 V
PRS07G   - 400 V
PRS07J   - 600 V
VRWM crest working reverse voltage   -
PRS07D   - 200 V
PRS07G   - 400 V
PRS07J   - 600 V
VR reverse voltage   -
PRS07D   - 200 V
PRS07G   - 400 V
PRS07J   - 600 V
IF(AV) average forward current Ttp = 65; Figure 1;
averaged over any 20 ms period		 - 1.7 A
Tamb = 45; Figure 2; mounted on a printed-circuit board; Figure 6;
averaged over any 20 ms period		 - 0.6 A
IFRM repetitive peak forward current Ttp = 105 - 13 A
Tamb = 60 - 5.5 A
IFSM non-repetitive peak forward current tp = 8.3 ms half sine wave;
Tj = 150 prior to surge; VR = VRRM(max)		 - 20 A
Tstg storage temperature   -65 +150
Tj junction temperature   -65 +150



Description

PRS07,Fast soft-recovery rectifier diodes in a cavity free cylindrical glass surface mounted package using Implotec™ technology.
