Purchase PS196-315, In-stock PS196-315 From SeekIC.
MFG:ALPHA
Part Number: PS196-315
MFG: ALPHA
Description: The PS196-315 is a voltage controlled phase shifter specifically designed for use in power amplifier d...
- Table of contents:
PS196-315
-
Suppliers
DataSheet
General Description
PS196-315 General Description
The PS196-315 is a voltage controlled phase shifter specifically designed for use in power amplifier distortion compensation circuits centered at 1960 MHz in PCS band base stations. Its characteristics are specified in a 60 MHz bandwidth. The PS196-315 employs a monolithic quadrature hybrid and a pair of selected silicon varactor diodes to achieve 100-degree phase shift and low insertion loss.The PS196-315 is packaged in the small outline LGA (Land Grid Array) surface mount package with the internal elements affixed to an organic BT substrate.
PS196-315 Maximum Ratings
|
Characteristic |
Value |
| RF Input Power |
20 dBm |
| Control Voltage |
15 V |
| Operating Temperature |
-40 to +85°C |
| Storage Temperature |
-40 to +85°C |
PS196-315 Features
Designed for PCS 1960 ± 30 MHz Band
100 Degree Phase Shift Range
1.5 Degree Phase Deviation
0.3 dB Insertion Loss Deviation
012 V Control Voltage Range
Specified 33 dBm IP3
Small Footprint LGA Package
100 Degree Phase Shift Range
1.5 Degree Phase Deviation
0.3 dB Insertion Loss Deviation
012 V Control Voltage Range
Specified 33 dBm IP3
Small Footprint LGA Package
