General Description
PT360 General Description
The PT360 is compact type phototransistor. It is suitable for the floppy disk drives, VCRs, video camera, optoelectronic switches.
Features of the PT360 are:(1)3.2mm compact type epoxy resin package;(2)intermediate acceptance (:typ.±20°);(3)lead pins space:2.54mm.
The absolute maximum ratings of the PT360 can be summarized as:(1)collector-emitter voltage:35V;(2)emitter-collector voltage:6V;(3)collector current:20mA;(4)collector power dissipation:50mW;(5)operating temperature:-25 to +85;(6)storage temperature:-25 to +85;(7)soldering temperature:260.
The electrical characteristics of the PT360 are:(1)collecotr current:75uA to 420uA, 200uA(typ.);(2)collector dark current:2*10-9 A to 10-7 A;(3)collector-emitter saturation voltage:0.2V to 0.4V;(4)peak sensitivity wavelength:800nm;(5)response time(rise):10us to 40us;(6)response time(fall):8us to 35us.
If you want to know more information such as the electrical characteristics about the PT360, please download the datasheet in www.seekic.com or www.chinaicmart.com .
