QR1430T30

Features: · Fast Recovery Time· Isolated Mounting· Metal Baseplate· Low Thermal Impedance· 3000 V isolating voltageApplication· Switching Power Supplies· Inverters· Choppers· Welding Power Supplies· Free Wheeling Diode· High Frequency RectifiersSpecifications Characteristics Conditions Sy...

product image

QR1430T30 Picture
See larger image
SeekIC No. : 004468362 Detail

QR1430T30: Features: · Fast Recovery Time· Isolated Mounting· Metal Baseplate· Low Thermal Impedance· 3000 V isolating voltageApplication· Switching Power Supplies· Inverters· Choppers· Welding Power Supplies·...

QR1430T30 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
QR1430T30
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/18

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Fast Recovery Time
· Isolated Mounting
· Metal Baseplate
· Low Thermal Impedance
· 3000 V isolating voltage


Application

· Switching Power Supplies
· Inverters
· Choppers
· Welding Power Supplies
· Free Wheeling Diode
· High Frequency Rectifiers


Specifications

Characteristics Conditions
Symbol
QRD1430T30
QRC1430T30
QRF1430T30
Units
Repetitive Peak Reverse Blocking Voltage -
VRRM
1400
Volts
Non-Repetitive Peak Reverse Blocking Voltage -
VRSM
VRRM + 100
Volts
Average Forward Current 180° Conduction, Tc=25°C
IF(AV)
300
Amperes
Peak Half Cycle Non-Repetitive Surge Current t = 8.3mS, 100%VRRM Reapplied
IFSM
2000
Amperes
I2t for Fusing for One Cycle
 t = 8.3mS, 100%VRRM Reapplied
I2t
16670
A2sec
Operating Junction Temperature -
TJ
-40 to 150
°C
Storage Temperature -
TSTG
-40 to 150
°C
Maximum Mounting Torque, M6 Mounting Screw -
-
26
In.-lb.
Maximum Terminal Torque, M6 Terminal Screw -
-
26
In.-lb.
Module Weight (Typical) 60 Hz, circuit to base, all terminals
-
220
Grams
V Isolation shorted, t = 1 sec
VRMS
3000
Volts



Description

Powerex Fast Recovery Diode Modules QR1430T30 are designed for use in applications requiring fast switching. The modules are isolated for easy mounting with other components on a common heatsink.
