R1113Z

Features: ·Ultra-Low Supply Current......................................... Typ. 100µA·Standby Mode ........................................................... Typ. 0.1µA·Low Dropout Voltage ................................................ Typ. 0.23V(IOUT=100mA 3.0V Output type)·High ...

product image

R1113Z Picture
See larger image
SeekIC No. : 004468876 Detail

R1113Z: Features: ·Ultra-Low Supply Current......................................... Typ. 100µA·Standby Mode ........................................................... Typ. 0.1µA·Low Dropout Vo...

R1113Z Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
R1113Z
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Ultra-Low Supply Current......................................... Typ. 100µA
·Standby Mode ........................................................... Typ. 0.1µA
·Low Dropout Voltage ................................................ Typ. 0.23V(IOUT=100mA 3.0V Output type)
·High Ripple Rejection ............................................... Typ. 80dB(f=1kHz 3.0V Output type)
·Low Temperature-Drift Coefficient of Output Voltage Typ. ±100ppm/°C
·Excellent Line Regulation ......................................... Typ. 0.05%/V
·High Output Voltage Accuracy.................................. ±2.0%
·Excellent Dynamic Response
·Small Package ..........................................................WL-CSP(Wafer Level CSP)
·Output Voltage...........................................................Stepwise setting with a step of 0.1V in the range of 2.0V to 5.0V is possible
·Built-in Chip Enable Circuit ( 2 types; A: active low , B: active high)
·Built-in Fold Back Protection Circuit........................Typ. 30mA (Current at short mode)
·Ceramic capacitors are recommended to be used with this IC


Application

·Power source for cellular phones such as GSM, CDMA and various kinds of PCS.
·Power source for electrical appliances such as cameras, VCRs and camcorders.
·Power source for battery-powered equipment.


Specifications

Item Symbol Rating Unit
Input Voltage VIN 7.0 V
Input Voltage( CE or CE Pin) VCE -0.3 ~ VIN+0.3 V
Output Voltage VOUT -0.3 ~ VIN+0.3 V
Output Current IOUT 200 mA
Power Dissipation PD 190 mW
Operating Temperature Range Topt -40 ~ 85 °C
Storage Temperature Range Tstg -55 ~ 125 °C



Description

The R1113Z Series are CMOS-based voltage regulator ICs with high output voltage accuracy, extremely low supply current, low ON-resistance, and high ripple rejection. Each of R1113Z consists of a voltage reference unit, an error amplifier, resistors, a current limit circuit, and a chip enable circuit.

The R1113Z perform with low dropout voltage and a chip enable function. The line transient response and load transient response of the R1113Z Series are excellent, thus these ICs are very suitable for the power supply for hand-held communication equipment.

The output voltage of R1113Z is fixed with high accuracy. Since the package for these ICs is WL-CSP (Wafer Level CSP), high density mounting of the ICs on boards is possible.
