RC56D-USB

Features: · All features supported by the RC56D family (see data sheet Order No. MD211)· Universal Serial Bus Specification Rev 1.0 compliant· Three function endpoint pairs with corresponding transmit/receive FIFO pairs· Automatic transmit/receive FIFO management· USB full speed 12Mbps· USB low sp...

product image

RC56D-USB Picture
See larger image
SeekIC No. : 004472630 Detail

RC56D-USB: Features: · All features supported by the RC56D family (see data sheet Order No. MD211)· Universal Serial Bus Specification Rev 1.0 compliant· Three function endpoint pairs with corresponding transm...

RC56D-USB Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
RC56D-USB
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· All features supported by the RC56D family (see data sheet Order No. MD211)
· Universal Serial Bus Specification Rev 1.0 compliant
· Three function endpoint pairs with corresponding transmit/receive FIFO pairs
· Automatic transmit/receive FIFO management
· USB full speed 12Mbps
· USB low speed 1.5Mbps
· Reset separation
· Four LED driver outputs
· On-chip phase-locked loop (PLL)
· On-chip USB transceivers
· 256 bytes on-chip Data RAM
· Suspend/Resume
· Vendor specific descriptors
· Windows 98 support
· Windows 95 OSR 2.1 support
· Extension pickup/remote hang-up detection
· Line-in-use detection


Pinout

Connection Diagram


Description

The CONEXANTä RC56D Modem Device Set supports the USB (Universal Serial Bus), as described by the Universal Serial Bus Specification Revision 1.0. USB provides a flexible interconnect between a PC and a wide range of peripherals, such as to a CONEXANT modem device set.

The CONEXANT RC56D family devices, in conjunction with the R8292 USB controller provide a complete USB modem solution. The supported modem feature set for the USB modem solution is the same as the standard RC56D parallel host interface device set (see "RC56D and RC336D Integrated V.90/K56flex/V.34 Modem Device Set for Desktop Applications" Data Sheet, Order No. MD211). The modem models, which include the R8292 UCU (USB Controller Unit in 68-PLCC), are listed in Table 1.
