RF2323

The RF2323 is a general purpose, low-cost silicon ampli-fier designed for operation from a 3V supply. The circuit RF2323 configuration with resistive feedback allows for broad-band cascadable amplification. Capacitive compensation extends the bandwidth of the amplifier and input stage design optimizes noise figure. The device is uncondition-ally stable and internally matched to 50. The only exter-nal components required for specified performance are bypass and DC blocking capacitors (as shown in applica-tion schematic). The RF2323 is available in a very small
industry-standard SOT-23 5-lead surface mount package,enabling compact designs which conserve board space.
