RF2381

Features:

50dB Linear Gain Control Range
22dBMaximumGain
Single 2.7V to 3.3V Supply
35mA Supply Current
High Linearity




Application

CDMA PCS/Cellular Handsets
TDMA PCS/Cellular Handsets
W-CDMA Handsets




Pinout






Specifications

Parameter	Rating	Unit
Supply Voltage DC Current Operating Ambient Temperature Storage Temperature	0 to +5.0 100 -30 to +85 -40 to +150	VDC mA °C °C

Frequency (MHz)

800 to 2100

Gain (dB)

20 at 1880

OP1dB (dBm)

8

OIP3 (dBm)

26

Gain Control Range (dB)

50

Vcc (V)

2.7 to 3.3

Icc (mA)

35

Package/Size (Dim in mm)

SOT23-6

Description

The RF2381 is a linear variable gain amplifier suitable for use in TDMA and CDMA systems in the cellular or PCS band and for W-CDMA systems. The features of RF2381 include linear gain control, high gain, and high lin-earity. The IC is manufactured on an advanced Gallium Arsenide Heterojunction Bipolar Transistor (GaAs HBT) process and is featured in an industry-standard miniature 6-lead plastic SOT package.
