RGL34

Fast switching device: 1st band is Red

SYMBOLS

RGL34A

RGL34B

RGL34D

RGL34G

RGL34J

UNITS

Polarity color bands (2nd Band)

Gray

Red

Orange

Yellow

Green

Maximum repetitive peak reverse voltage

V_RRM

50

100

200

400

600

Volts

Maximum RMS voltage

V_RMS

35

70

140

280

420

Volts

Maximum DC blocking voltage

V_DC

50

100

200

400

600

Volts

Maximum average forward rectified current
0.375" (9.5mm) lead lengths at TA=55°C

I_(AV)

1.0

Amps

Peak forward surge current
8.3ms single half sine-wave superimposed
on rated load (JEDEC Method)

I_FSM

10.0

Amps

Maximum instantaneous forward voltage at 3.0A

V_F

1.3

Volts

Maximum DC reverse current TA=25°C
at rated DC blocking voltage TA=125°C

I_R

5.0
50.0

mA

Maximum average reverse current TA=25°C
at peak reverse voltage TA=100°C

I _R(AV)

50.0
100.0

mA

Maximum reverse recovery time (NOTE 1)

t_rr

150

ns

Typical junction capacitance (NOTE 2)

CJ

8.5

pF

Maximum thermal resistance (NOTE 3)
(NOTE 4)

RQJA
RQJL

150.0
70.0

°C/W

Operating junction and storage temperature range

TJ, TSTG

-65 to +175

°C
