RL806

Rectifiers 8A 800V

product image

RL806 Picture
See larger image
SeekIC No. : 00170310 Detail

RL806: Rectifiers 8A 800V

RL806 Data Sheet

floor Price/Ceiling Price

US $ .37~.53 / Piece | Get Latest Price
Part Number:
RL806
Mfg:
Rectron
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~100
  • 100~500
  • 500~1000
  • Unit Price
  • $.53
  • $.48
  • $.43
  • $.37
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/28

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Standard Recovery Rectifiers Configuration : Single
Reverse Voltage : 800 V Forward Voltage Drop : 1.1 V
Forward Continuous Current : 8 A Max Surge Current : 200 A
Reverse Current IR : 10 uA Mounting Style : Through Hole
Package / Case : TO-220A Packaging : Bulk

Description

Recovery Time :
Forward Voltage Drop : 1.1 V
Packaging : Bulk
Configuration : Single
Forward Continuous Current : 8 A
Product : Standard Recovery Rectifiers
Reverse Voltage : 800 V
Mounting Style : Through Hole
Max Surge Current : 200 A
Reverse Current IR : 10 uA
Package / Case : TO-220A


Features:

* Low Ieakage
* Low forward voltage drop
* High current capability
* High surge capability
* High reliability


Specifications
SYMBOL
RL801
RL802
RL803
RL804
RL805
RL806
UNITS
Maximum Recurrent Peak Reverse Voltage
VRRM
50
100
200
400
600
800
Volts
Maximum RMS Voltage
VRMS
35
70
140
280
420
560
Volts
Maximum DC Blocking Voltage
VDC
50
100
200
400
600
800
Volts
Average forward current
at TC=100(Note 1)
IO
8.0
Amps
Peak Forward Surge Current, 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
IFSM
200
Amps
Typical junction capacitance
CJ
3.6
F
Typical junction capacitance (Note 2)
RJA
40
/W
Operating and Storage Temperature Range
TJ, TSTG
-65 to +150
