RS-05FS

The RS-05FS is designed as reflective sensor which combines a GaAs infrared light emitting diode with a high sensitive phototransistor in a super mini chip-type package, reducing installation space. Typical applications include timing sensors, edge sensors, micro floppy disc drives and level sensors of liquid.

RS-05FS has five features. (1)Compact. (2)High performance. (3)High speed response. (4)Easy to mount PCB. (5)Widely applicable. Those are all the main features.

Some absolute maximum ratings of RS-05FS have been concluded into several points as follow. (1)Its input power dissipation would be 75mW. (2)Its reverse voltage would be 5V. (3)Its forward current would be 50mA. (4)Its pulse forward current would be 1A. (5)Its collector power dissipation would be 50mW. (6)Its collector current would be 20mA. (7)Its collector to emitting voltage would be 30V. (8)Its emitting to collector voltage would be 3V. (9)Its operating temperature range would be from -25°C to +85°C. (10)Its storage temperature range would be from -30°C to +95°C. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to device.

And some electrical characteristics of RS-05FS are concluded as follow. (1)Its forward voltage would be max 1.3V at If=10mA. (2)Its reverse current would be max 10uA with conditions of Vr=5V. (3)Its capacitance would be typ 25pF with conditions of V=0V, f=1kHz. (4)Its peak wavelegth would be typ 940nm. (5)Its collector dark current would be max 0.2uA with conditions of Vce=10V. (6)Its leakage current would be max 0.2uA with conditions of Vce=5V, If=10mA. (7)Its light current would be min 90uA with conditions of Vce=5V, If=10mA. (8)Its switching speeds rise time would be typ 30usec with conditions ov Vcc=2V, Ic=100uA and RL=1kohms. (9)Its switching speeds fall time would be typ 25usec. And so on. If you have any question or suggestion or want to know more information please contact us for details. Thank you!
