RF Receiver 2G ASH Receiver 315MHz 19.2kbps
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Type : | ASH Receiver Module | Package / Case : | SM-20L |
Operating Frequency : | 315.2 MHz | Operating Supply Voltage : | 2.5 V, 3.3 V |
Packaging : | Reel |
Rating |
Value |
Units |
Power Supply and All Input/Output Pins |
-0.3 to +4.0 |
V |
Non-Operating Case Temperature |
-50 to +100 |
°C |
Soldering Temperature (10 seconds.) |
230 |
°C |
The RX5501 hybrid receiver is ideal for short-range wireless control applications where robust operation, small size, low power consumption and low cost are required. The RX5501 employs RFM's amplifier-sequenced hybrid (ASH) architecture to achieve this unique blend of characteristics. All critical RF functions are contained in the hybrid, simplifying and speeding design-in. The RX5501 is sensitive and stable. A wide dynamic range log detector provides robust performance in the presence of on-channel interference or noise. Two stages of SAW filtering provide excellent receiver out-of-band rejection. The RX5501 generates virtually no RF emissions, facilitating compliance with FCC Part 15 and similar regulations.
