S13MD01
-
Suppliers
DataSheet
General Description
S13MD01 Maximum Ratings
|
Parameter |
Symbol |
Rating |
Unit | |
| Input | Forward current |
IF |
50 |
mA |
| Reverse voltage |
VR |
6 |
V | |
| Output | RMS ON-state current |
IT |
0.3 |
ARMS |
| *1Peak one cycle surge current |
Isurge |
3 |
A | |
| Repetitive peak OFF-state voltage |
VDRM |
400 |
V | |
|
*2 Isolation voltage |
Viso |
4000 |
VRMS | |
|
Operating temperature |
TOPR |
- 25 to +80 |
||
|
Storage temperatrue |
TSTG |
- 40 to +125 |
||
|
*3 Soldering temperature |
TSOL |
260 |
||
*1 50Hz sine wave
*2 40 to 60% RH, AC for 1 minute, f=60Hz
*3 For 10 seconds
S13MD01 Features
1. Compact 8-pin dual-in-line package
2. RMS ON-state current (IT : 0.3Arms)
3. Repetitive peak OFF-state voltage is high.
4. Isolation voltage between input and output (Viso : 4000Vrms)
5. Recognized by UL (No. E94758)
6. Approved by CAS (No. LR63705)
2. RMS ON-state current (IT : 0.3Arms)
3. Repetitive peak OFF-state voltage is high.
4. Isolation voltage between input and output (Viso : 4000Vrms)
5. Recognized by UL (No. E94758)
6. Approved by CAS (No. LR63705)
S13MD01 Typical Application
1. Oil fan heaters
2. Microwave ovens
3. Refrigerators
2. Microwave ovens
3. Refrigerators
S13MD01
PDF/DataSheet Download
- Datasheet: S13MD01
- File Size: 56935 KB
- Manufacturer: SHARP [Sharp Electrionic Components]
- Click here to Download
