Purchase S15B-PH-SM4-TB(LF)(SN), In-stock S15B-PH-SM4-TB(LF)(SN) From SeekIC.

MFG:JST Sales America Inc (VA)  Category:Connectors

S15B-PH-SM4-TB(LF)(SN)

S15 Series Datasheet download

Five Points

Part Number: S15B-PH-SM4-TB(LF)(SN)

Category: Connectors

MFG: JST Sales America Inc (VA)





Descriptions: CONN HEADR PH SIDE 15POS 2MM SMD

Price Break

10
100
500

Unit Price

1.25900
1.04910
.83926

Extended Price

12.59
104.91
419.63

(All prices are in USD) Prices for reference only
Urgent Purchase

S15B-PH-SM4-TB(LF)(SN) General Description

CONN HEADR PH SIDE 15POS 2MM SMD

S15B-PH-SM4-TB(LF)(SN) Parameters

Technical/Catalog InformationS15B-PH-SM4-TB(LF)(SN)
VendorJST Sales America Inc (VA)
CategoryConnectors
ColorNatural
Connector TypeHeader, Shrouded
Contact FinishTin
Contact Mating Length-
Features-
Mounting TypeSurface Mount, Right Angle
Number of Contacts LoadedAll
Number of Rows1
Pitch0.079" (2.00mm)
Row Spacing-
PackagingCut Tape (CT)
Fastening Type-
TerminationSolder
Contact Finish Thickness-
Number of Positions 15
Contact TypeMale Pin
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names S15B PH SM4 TB LF SN
S15BPHSM4TBLFSN
455 1761 1 ND
45517611ND
455-1761-1

S15B-PH-SM4-TB(LF)(SN) datasheet

S150
PDF/DataSheet Download
