S2025RTP

Maximum Gate Peak Inverse Voltage :
Mounting Style : Through Hole
Packaging : Reel
Forward Voltage Drop : 1.6 V
Gate Trigger Voltage (Vgt) : 1.5 V
Package / Case : TO-220
Rated Repetitive Off-State Voltage VDRM : 200 V
Off-State Leakage Current @ VDRM IDRM : 0.01 mA
Breakover Current IBO Max : 350 A
On-State RMS Current (It RMS) : 25 A
Gate Trigger Current (Igt) : 35 mA
Holding Current (Ih Max) : 50 mA


Parameters:

Technical/Catalog Information	S2025RTP
Vendor	Littelfuse / Teccor Brand Thyristors
Category	Discrete Semiconductor Products
SCR Type	Standard Recovery
Voltage - Off State	200V
Current - On State (It (RMS) (Max)	25A
Current - On State (It (AV)) (Max)	16A
Current - Gate Trigger (Igt) (Max)	30mA
Current - Hold (Ih) (Max)	40mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	300A, 350A
Voltage - Gate Trigger (Vgt) (Max)	1.5V
Mounting Type	Through Hole
Package / Case	TO-220
Packaging	Tube
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	S2025RTP S2025RTP
