S202S02
-
Suppliers
DataSheet
General Description
S202S02 Maximum Ratings
|
Parameter |
Symbol |
Rating |
Unit | ||
| S102S01 S102S02 |
S202S01 S202S02 | ||||
|
Inpu |
Forward current |
IF |
50 |
mA | |
| Reverse voltage |
VR |
6 |
V | ||
|
Output |
RMS ON-state current |
IT |
8 |
Arms | |
| *1 Peak one cycle surge current |
VDRM |
80 |
A | ||
| Repetitive peak OFF-state voltage |
VDRM |
400 |
600 |
V | |
| Non-repetitive peak OFF-state voltage |
Isurge |
400 |
600 |
V | |
| Critical rate of rise of ON-state current |
dIT/dt |
50 |
A/s | ||
| Operating frequency |
f |
45 to 65 |
Hz | ||
| *2 Isolation voltage |
Viso |
4 000 |
Vrms | ||
| Operating temperature |
Topr |
- 25 to + 100 |
|||
| Storage temperature |
Tstg |
- 30 to + 125 |
|||
| *3 Soldering temperature |
Tsol |
260 |
|||
*1 TC<=80
*2 50Hz sine wave, Tj =25 start
*3 60Hz AC for 1 minute, 40 to 60% RH, Apply voltages between input and output, by the dielectric withstand voltage tester with zero-cross circuit. (Input and output shall be shorted respectively).
(Note) When the isolation voltage is necessary at using external heat sink, please use the insulation sheet.
*4 For 10 seconds
S202S02 Features
` High radiation resin mold package
` RMS ON-state current
IT :8 Arms at TC <= 80
(With heat sink)
` Built-in zero-cross circuit
(S102S02/S202S02)
` High repetitive peak OFF-state voltage
S102S01/S102S02 VDRM: MIN. 400V
S202S01/S202S02 VDRM: MIN. 600V
` Isolation voltage between input and output
( Viso : 4 000Vrms )
` Approved by CSA, No. LR63705
Recognized by UL, file No. E94758
` RMS ON-state current
IT :8 Arms at TC <= 80
(With heat sink)
` Built-in zero-cross circuit
(S102S02/S202S02)
` High repetitive peak OFF-state voltage
S102S01/S102S02 VDRM: MIN. 400V
S202S01/S202S02 VDRM: MIN. 600V
` Isolation voltage between input and output
( Viso : 4 000Vrms )
` Approved by CSA, No. LR63705
Recognized by UL, file No. E94758
S202S02 Typical Application
· Automatic vending machines, programmable controllers
· Amusement equipment
S202S02
