S30L60

The S30L60 is designed as one kind of super fast recovery rectifiers with voltage of 600V and current of 30A. Its typical applications include PFC, switching power supply, free wheel, home appliances, office equipment and factory automation.

S30L60 has three features. (1)It has high voltage. (2)Its trr would be 150ns. (3)It has small jc. Those are all the main features.

Some absolute maximum ratings of S30L60 have been concluded into several points as follow. (1)Its storage temperature range would be from -55°C to 150°C. (2)Its operating junction temperature would be 150°C. (3)Its maximum reverse voltage would be 600V. (4)Its average rectified forward current would be 30A with conditions of 50Hz sine wave and R-load and Tc=117°C. (5)Its peak surge forward current would be 600A with conditions of 50Hz sine wave and non-repetitive 1 cycle value and Tj=25°C. (6)Its mounting torque would be 0.8Nm with notice of recommended torque 0.5Nm. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to S30L60.

Also some electrical characteristics of S30L60 (if not specified the Tc would be 25°C) are concluded as follow. (1)Its forward voltage with symbol of Vf would have the maximum value of 1.5V with conditions of If=30A and pulse measurement. (2)Its reverse current with symbol of Ir would have the maximum value of 25uA with conditions of Vr=Vrm and pulse measurement. (3)Its reverse recovery time would have the maximum value of 150ns with conditions of If=0.5A and Ir=1A. (4)Its thermal resistance would have the maximum value of 0.7°C/W with conditions of junction to case. And so on. At present we have not got so much information about this IC and we would try hard to get more information about it. If you have any question or suggestion or want to know more information about S30L60 please visit our website and contact us for details. Thank you!
