SB40-03T

Features: · Low forward voltage (VF max=0.55V).· Fast reverse recovery time (trr max=30ns).· Low switching noise.· Low leakage current and high reliability due to highly reliable planar structure.Application· High frequency rectification (switching regulators,converters, choppers).Pinout Specifica...

product image

SB40-03T Picture
See larger image
SeekIC No. : 004484753 Detail

SB40-03T: Features: · Low forward voltage (VF max=0.55V).· Fast reverse recovery time (trr max=30ns).· Low switching noise.· Low leakage current and high reliability due to highly reliable planar structure.Ap...

SB40-03T Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SB40-03T
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Low forward voltage (VF max=0.55V).
· Fast reverse recovery time (trr max=30ns).
· Low switching noise.
· Low leakage current and high reliability due to highly reliable planar structure.




Application

· High frequency rectification (switching regulators,converters, choppers).




Pinout






Specifications

Absolute maximum ratings
VRRM VRM* [V] 30
IO [A] 4
IFSM [A] 40
Electrical characteristics
VF max [V] 0.55
IF [A] 4
Tj [°C] -
IR max [µA] 200
VR [V] 15
Tj [°C] -
trr max [ns] 30
IF=IR [mA] 300
Tj [°C] -
Rthj-a typ [°C/W] 90


Parameter

Symbol

CONDITIONS

Rating

Unit

Repetitive Peak Reverse Voltage

VRRM

30

V

Nonrepetitive Peak Reverse Surge Voltage

VRSM

35

V

Average Output Current

Io

50Hz, resistive load, Tc=105˚C

4

A

Surge Forward Current

IFSM

50Hz sine wave, 1cycle

40

A

Junction Temperature

TJ

-55 to+125

˚C

Storage Temperature

TSTG

-55 to+125

˚C
