Purchase SBLB1030CT, In-stock SBLB1030CT From SeekIC.
MFG:GSI Package Cooled:TO-263 D/C:05+
- Table of contents:
SBLB1030CT
-
Suppliers
DataSheet
General Description
SBLB1030CT Maximum Ratings
|
|
Symbols |
SBLB1030CT |
SBLB1040CT |
Units |
|
Maximum Recurrent Peak Reverse Voltage |
VRRM |
30 |
40 |
Volts |
|
Maximum RMS Voltage |
VRMS |
21 |
28 |
Volts |
|
Maximum DC Blocking Voltage |
VDC |
30 |
40 |
Volts |
|
Maximum Average Forward Rectified Current at Tc = 95 |
I(AV) |
10.0 |
Amps | |
|
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC method ) |
IFSM |
175.0 |
Amps | |
|
Maximum instantaneous forward Voltage par leg at 5.0A(Note 1) |
VF |
0.55 |
Volts | |
|
Maximum instantaneous Current @ Tc=25 |
IR |
0.5 |
mA | |
| Typical Thermal Resistance par leg(Note 2) |
RJC |
3.0 |
/W | |
|
Operating junction and Storage Temperature Range |
TJ ,TSTG |
-40 to +125 |
||
SBLB1030CT Features
Plastic package has Underwriters Laboratory Flammability Classifications 94V-0
Metal silicon junction, majority carrier conduction
Low power loss,high efficiency
High current capability,low forward voltage drop
High surge capacity
For use in low voltage, high frequency inverters, free wheeling, and polarity protection applications
Guardring for overvoltage protection
High temperature soldering in accordance with CECC 802 / Reflow guaranteed
Metal silicon junction, majority carrier conduction
Low power loss,high efficiency
High current capability,low forward voltage drop
High surge capacity
For use in low voltage, high frequency inverters, free wheeling, and polarity protection applications
Guardring for overvoltage protection
High temperature soldering in accordance with CECC 802 / Reflow guaranteed
