SC1454

The SC1454 is designed as dual 150mA ultra low dropout, low noise regulator which contains two ultra low dropout voltage regulators (ULDOs). It operates from an input voltage range of 2.25V to 6.5V and a wide variety of output voltage options are available. One ULDO has a fixed output, and the other is either fixed (SETA pin grounded) or adjustable using external resistors. Each ULDO has an independent enable pin.

SC1454 has eleven features. (1)Up to 150mA per regulator output. (2)Low quiescent current. (3)Low dropout voltage. (4)Stable operation with ceramic caps. (5)Very low 50uVrms output noise. (6)Wide selection of output voltages. (7)Tight load and line regulation. (8)Current and thermal limiting. (9)Reverse input polarity protection. (10)<1.5uA off-mode current. (11)Logic controlled enable. Those are all the main features.

Some absolute maximum ratings of SC1454  have been concluded into several points as follow. (1)Its input supply voltage would be from -5V to 7V. (2)Its enable input voltage would be from -5V to Vin. (3)Its operating ambient temperature range would be from -40°C to 85°C. (4)Its operating junction temperature range would be from -40°C to 125°C. (5)Its storage temperature range would be from -60°C to 150°C. (6)Its thermal impedance junction to ambient would be 206°C/W for minimum pad size and would be 95°C/W for 1 square inch of FR-4, double sided 1oz, minimum copper weight. (7)Its thermal impedance junction to case would be 39°C/W. (8)Its ESD rating (human body model) would be 2kV. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to device.

Also some electrical characteristics of SC1454  are concluded as follow. (1)Its input supply voltage would be min 2.25V and max 6.5V. (2)Its quiescent current would be typ 100uA and max 150uA at Vena=0V and Venb=Vin, Ioutb=150mA and it would be max 200uA at Venb=0V, Vena=Vin, Iouta=150mA. And so on. If you have any question or suggestion or want to know more information please contact us for details. Thank you!
