FM input with pre-scalar for radio frequency up to 150 MHz
AM input for radio frequency up to 30 MHz
3 common, 13 segment, 1/3 bias LCD display drivers which supports 4 digits LCD display
On chip oscillator for external 32.768kHz crystal
10.7 MHz / 70 kHz I.F. frequency offset for FM signal and 455kHz I.F. frequency offset for AM signal
Internal real time clock in 12 hour display mode
Selectable clock or frequency display
1.8V to 3.3V supply voltage
Characteristic | Symbol | Value | Unit |
Supply Voltage | VDD | 0.5 ~7.0 | V |
Input or Output Voltage | VIN, VOUT | -0.5 ~ VDD+0.5 | V |
Storage Temperature | TSTG | -40 ~ +125 | °C |
ESD Protection | -2 ~ + 2 | kV |
The SC3610 is a frequency and clock display driver used for displaying FM/AM radio frequency or a 12 hour alarm clock. By using CMOS technology, it consumes very low power in clock display mode.
