SCC15A

The SCC series SCC15A offer an extremely low cost sensor element with a temperature stable output when driven with a constant current source. These integrated circuit sen-sors were designed for extremely cost sensitive applications where precise accuracy over a wide temperature range is not required. This series is intended for use with non-corrosive, non-ionic working fluids such as air and dry gases.

Absolute devices SCC15A have an internal vacuum reference and an output voltage proportional to applied pressure. The differential devices allow application of pressure to either side of the diaphragm and the devices are thereby available to measure both differential and/or gage pressures.

This SCC15A is packaged either in SenSym´s standard low cost chip carrier "button" package, a plastic ported "N" package, a metal package or a dual inline package (DIP). All packages are designed for applications where the sensing element is to be integral to the OEM equipment. These packages can be O-ring sealed, epoxied, and/or clamped onto a pressure fitting. A closed bridge four-pin SIP configuration isprovided for electrical connection to the button package. The TO can and the DIP offer a 5-pin open bridge configuration
