SD214 General Description


The Calogic SD210 is a 30V analog switch driver without a built-in protection diode from gate to substrate for use with SD212 and SD214 DMOS analog switches.

SD214 Maximum Ratings

Drain Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50mA
Total Device Dissipation at 25Case Temperature . . . . . .1.2W
Storage Temperatue Range . . . . . . . . . . . . . . .-65 to +200oC
Lead Temperature (1/16" from case for 10 sec.) . . . . . .  300oC
Operating Temperature Range . . . . . . . . . . .  -55oC to +125oC

SD214 Features

High Input to Output Isolation . . . . . . . . . . . . . . . .  120dB
Low On Resistance . . . . . . . . . . . . . . . . . . . . . . . . 30 Ohm
Low Feedthrough and Feedback Transients
Low Capacitance:
Input (Gate). . . . . . . . . . . . . . . . . . . . . . . . . . .  2.4pF typ.
Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  1.3pF typ.
Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . .  0.3pF typ.
No protection Diode from Gate to Substrate for Very High Impedance     Applications
Maximum Gate Voltage . . . . . . . . . . . . . . . . . . . . . . .  ±40V

SD214 Typical Application

Analog Switches
High-Speed Digital Switches
Multiplexers
A to D Converters
D to A Converters
Choppers
Sample & Hold
