Part Number: SE521



MFG: S/PHI

Package Cooled: CDIP16

D/C: --



Urgent Purchase

SE521 Maximum Ratings

SYMBOL SYMBOL RATING UNIT
V+
V-		 Supply voltage
Positive
Negative		 +7
-7		 V
V
VIDR Differential input voltage ±6 V
VIN Input voltage
Common mode
Strobe/gate		 ±5
+5.25		 V
V
PD Maximum power dissipation1
TA= 25°C (still-air)
F package
N package
D package		 1190
1420
1040		 mW
mW
mW
TA Operating temperature range
NE521
SE521		 0 to 70
-55 to +125		 °C
°C
TSTG Storage temperature range -65 to +150 °C
TSOLD Lead soldering temperature (10 sec. max) +300 °C
1. Derate above 25°C at the following rates:
F package at 9.5mW/°C
N package at 11.4mW/°C
D package at 8.3mW/°C

SE521 Features

• 12ns maximum guaranteed propagation delay
• 20mA maximum input bias current
• TTL compatible strobes and outputs
• Large common-mode input voltage range
• Operates from standard supply voltages
• Military qualifications pending

SE521 Typical Application

• MOS memory sense amp
• A-to-D conversion
• High-speed line receiver

SE521 Connection Diagram

SE521 Connection Diagram

SE521 datasheet

SE521
PDF/DataSheet Download
