SF5LC40

Product : Ultra Fast Recovery Rectifiers
Packaging : Bulk
Forward Continuous Current : 5 A
Mounting Style : Through Hole
Max Surge Current : 50 A
Reverse Voltage : 400 V
Reverse Current IR : 10 uA
Recovery Time : 50 ns
Configuration : Dual Common Cathode
Forward Voltage Drop : 1.3 V at 2.5 A
Package / Case : FTO-220


Specifications




Description

The features of SF5LC40 are: (1)low noise; (2)trr50ns; (3)fully isolated molding; (4)dielectric stregth 2kV guaranteed.

The following is about the absolute maximum ratings of SF5LC40: (1)storage temperature: -40 to 150; (2)operating junction temperature: 150; (3)maximum reverse voltage: 400V; (4)average rectified forward current: 5A; (5)peak surge forward current: 50A; (6)dielectric strength: 2kV; (7)mounting torque: 0.5Nm.

The electrical characteristics of the SF5LC40 are: (1)forward voltage: 1.3V max; (2)reverse current: 10A; (3)total gate charge: 50pF; (4)thermal resistance: 2.3/W.
