SF67

Product : Ultra Fast Recovery Rectifiers
Packaging : Reel
Configuration : Single
Reverse Current IR : 5 uA
Mounting Style : Through Hole
Forward Continuous Current : 6 A
Max Surge Current : 150 A
Package / Case : DO-201AD
Recovery Time : 35 ns
Forward Voltage Drop : 1.7 V
Reverse Voltage : 500 V


Features:

* Low forward voltage drop
* High current capability
* High reliability
* High surge current capability
* Good for switching mode application

Specifications

Rating 25 ambient temperature uniess otherwies specified.Single phase half wave, 60Hz, resistive or inductive load.For capacitive load, derate current by 20%.

RATINGS	SF61	SF62	SF63	SF64	SF65	SF66	SF67	Units
Maximum repetitive peakreverse voltage	50	100	150	200	300	400	600	V
Maximum RMS volts	35	70	105	140	210	280	420	V
Maximum DC Blocking Voltage	50	100	150	200	300	400	600	V
Maximum average forward current (Note 1) at TA=55	6.0							A
Non-Repetitive Peak Forward Surge Current 8.3ms Single half sine-wave superimposed on rated load (JEDEC Method)	150							A
Maximum forward voltage at@IF=6.0A	0.95				1.25		1.50	V
Maximum DC Reverse Current @ TA=25 at Rated DC Blocking Voltage @ TA=100	5.0 50							A
Maximum Reverse Recovery Time (Note 1)	35							ns
Typical Junction Capacitance (Note 2)	50							pF
Operating and Storage Temperature Range TJ, TSTG	-65 to +125

NOTES:
         1. Reverse Recovery Time test condition: IF=0.5A, IR=1.0A, IRR=0.25A
         2. Measured at 1MHz and applied reverse voltage of 4.0V D.C.
