SG1845

Features: · OPTIMIZED FOR OFF-LINE CONTROL· LOW START-UP CURRENT (<1mA)· AUTOMATIC FEED FORWARD COMPENSATION· TRIMMED OSCILLATOR DISCHARGE CURRENT· PULSE-BY-PULSE CURRENT LIMITING· ENHANCED LOAD RESPONSE CHARACTERISTICS· UNDER-VOLTAGE LOCKOUT WITH 6V HYSTERESIS (SG1844 only)· DOUBLE PULSE SUPPR...

product image

SG1845 Picture
See larger image
SeekIC No. : 004488939 Detail

SG1845: Features: · OPTIMIZED FOR OFF-LINE CONTROL· LOW START-UP CURRENT (<1mA)· AUTOMATIC FEED FORWARD COMPENSATION· TRIMMED OSCILLATOR DISCHARGE CURRENT· PULSE-BY-PULSE CURRENT LIMITING· ENHANCED LOAD ...

SG1845 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SG1845
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2026/5/1

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· OPTIMIZED FOR OFF-LINE CONTROL
· LOW START-UP CURRENT (<1mA)
· AUTOMATIC FEED FORWARD COMPENSATION
· TRIMMED OSCILLATOR DISCHARGE CURRENT
· PULSE-BY-PULSE CURRENT LIMITING
· ENHANCED LOAD RESPONSE CHARACTERISTICS
· UNDER-VOLTAGE LOCKOUT WITH 6V HYSTERESIS (SG1844 only)
· DOUBLE PULSE SUPPRESSION
· HIGH-CURRENT TOTEM-POLE OUTPUT
· INTERNALLY TRIMMED BANDGAP REFERENCE
· 500kHz OPERATION
· UNDERVOLTAGE LOCKOUT
    SG1844 - 16 volts
    SG1845 - 8.4 volts
· LOW SHOOT-THROUGH CURRENT <75mA OVER TEMPERATURE


Pinout

Connection Diagram


Specifications

Supply Voltage (ICC < 30mA) ...................................... Self Limiting
Supply Voltage (Low Impedance Source) ................................ 30V
Output Current (Peak) ............................................................±1A
Output Current (Continuous) ..............................................350mA
Output Energy (Capacitive Load) ............................................ 5µJ
Analog Inputs (Pins 2, 3) ....................................... -0.3V to +6.3V
Error Amp Output Sink Current .............................................10mA
Operating Junction Temperature
   Hermetic (J, Y, F, L Packages) ........................................... 150
   Plastic (N, M, D, DM Packages) ......................................... 150
Storage Temperature Range ................................-65 to +150
Lead Temperature (Soldering, 10 Seconds) ........................ 300

Note 1. Exceeding these ratings could cause damage to the device.
Note 2. All voltages are with respect to Pin 5. All currents are positive into the specified terminal.


Description

The SG1845 family of control ICs provides all the necessary features to implement off-line fixed frequency, current-mode switching power supplies with a minimum number of external components. Current-mode architecture demonstrates improved line regulation, improved load regulation, pulse-bypulse current limiting and inherent protection of the power supply output switch.

The bandgap reference is trimmed to ±1% over temperature. Oscillator discharge current is trimmed to less than ±10%. The SG1844/SG1845 has undervoltage and start-up current of less than 1mA.

The totem-pole output of SG1845 is optimized to drive the gate of a power MOSFET. The output is low in the off state to provide direct interface to an N-channel device.

Both operate of SG1845 up to a maximum duty cycle range of zero to <50% due to an internal toggle flip-flop which blanks the
output off every other clock cycle.

The SG1844/SG1845 is specified for operation over the full military ambient temperature range of -55 to 125.

The SG2844/SG1845 is specified for the industrial range of -25 to 85, and the SG3844/45 is designed for the commercial range of 0 to 70.
