General Description
SG317 General Description
The SG117A Series are 3-terminal positive adjustable voltage regulators which offer improved performance over the original 117 design. A major feature of the SG117A is reference voltage tolerance guaranteed within ± 1%, allowing an overall power supply tolerance to be better than 3% using inexpensive 1% resistors. Line and load regulation performance has been improved as well.
Additionally, the SG117A reference voltage is guaranteed not to exceed 2% when operating over the full load, line and power dissipation conditions. The SG117A adjustable regulators offer an improved solution for all positive voltage regulator requirements with load currents up to 1.5A.
SG317 Maximum Ratings
Power Dissipation .......................................Internally Limited
Input to Output Voltage Differential .................................40V
Storage Temperature Range .......................-65°C to 150°C
Note 1. Exceeding these ratings could cause damage to the device.
Input to Output Voltage Differential .................................40V
Storage Temperature Range .......................-65°C to 150°C
Note 1. Exceeding these ratings could cause damage to the device.
SG317 Features
· 1% output voltage tolerance
· 0.01%/V line regulation
· 0.3% load regulation
· Min. 1.5A output current
· Available in hermetic TO-220
· 0.01%/V line regulation
· 0.3% load regulation
· Min. 1.5A output current
· Available in hermetic TO-220
SG317 Typical Application
· Available to MIL-STD-883 and DESC SMD
· MIL-M38510/11704BYA - JAN117K
· MIL-M38510/11703BXA - JAN117T
· LMI level "S" processing available
· MIL-M38510/11704BYA - JAN117K
· MIL-M38510/11703BXA - JAN117T
· LMI level "S" processing available
