Part Number: SG3524
MFG: ST
Package Cooled: DIP
Description: This monolithic integrated circuit contains all the control circuitry for a regulating power supply in...
- Table of contents:
SG3524
-
Suppliers
DataSheet
General Description
SG3524 General Description
This monolithic integrated circuit contains all the control circuitry for a regulating power supply inverter or switching regulator. Included in a 16-pin dual-in-line package is the voltage reference, error amplifier, oscillator, pulse-width modulator, pulse steering flip-flop, dual alternating output switches and current-limiting and shut-down circuitry. This device can be used for switching regulators of either polarity, transformer-coupled DC-to-DC converters, transformerless voltage doublers and polarity converters, as well as other power control applications. The SG3524 is designed for commercial
SG3524 Maximum Ratings
|
Characteristic |
Symbol |
Ratings |
UNIT |
|
Power Dissipation
|
VIN |
40 |
mW |
|
IOUT |
100 |
mA | |
|
Forward Current |
IREF |
50 |
mA |
|
*1 Peak Forward Current |
-0.3 |
5 |
V |
|
Power dissipation Package limitation Derate above 25°C |
PD |
1000 8 |
°C |
|
Operating Temperature |
TA |
0 to +70 |
°C |
|
*2 Soldering Temperature |
TSTG |
260 for 5 seconds | |
SG3524 Features
• Complete PWM power control circuitry
• Single ended or push-pull outputs
• Line and load regulation of 0.2%
• 1% maximum temperature variation
• Total supply current is less than 10mA
• Operation beyond 100kHz
• Single ended or push-pull outputs
• Line and load regulation of 0.2%
• 1% maximum temperature variation
• Total supply current is less than 10mA
• Operation beyond 100kHz
SG3524 Connection Diagram
SG3524
PDF/DataSheet Download
- Datasheet: SG3524
- File Size: 84707 KB
- Manufacturer: TI [Texas Instruments]
- Click here to Download
