SG4000GXH26

Features of the SG4000GXH26 are:(1)repetitive peak off-state voltage:VDRM=4500V;(2)R.M.S. on-state current:IT(RMS)=1900A;(3)peak turn-off current:ITGQM=4000A;(4)critical rate of rise of on-state current:di/dt=500A/s;(5)critical rate of rise of off-state voltage:dv/dt=1000V/s.

The absolute maximum ratings of the SG4000GXH26 can be summarized as:(1):the characteristics is repetitive peak off-state voltage,the symbol is VDRM,the rating is 4500,the unit is V;(2):the characteristics is repetitive peak reverse voltage,the symbol is VRRM,the rating is 16,the unit is V;(3):the characteristics is peak turn-off current,the symbol is ITGQM,the rating is 4000(6F),3000(3F),the unit is A;(4):the characteristics is R.M.S on-state current,the symbol is IT(RMS),the rating is 1900,the unit is A;(5):the characteristics is peak one cycle surge on-state current(non-repetitive,10 ms width half sine waveform),the symbol is ITSM,the rating is 20000,the unit is A;(6):the characteristics is critical rate of rise of on-state current,the symbol is di/dt,the rating is 500,the unit is A/s;(7):the characteristics is peak forward gate current,the symbol is IFGM,the rating is 100,the unit is A;(8):the characteristics is average forward gate power dissipation,the symbol is PFG(AV),the rating is 100,the unit is W;(9):the characteristics is average reverse gate power dissipation,the symbol is PRG(AV),the rating is 300,the unit is W;(10):the characteristics is peak reverse gate voltage(at static),the symbol is VRGM,the rating is 16,the unit is V;(11):the characteristics is R.M.S gate current,the symbol is IG(RMS),the rating is 84,the unit is A;(12):the characteristics is junction temperature,the symbol is Tj,the rating is -40 to 125,the unit is ;(13):the characteristics is storage temperature range,the symbol is Tstg,the rating is -40 to 150,the unit is ;(14):the characteristics is mounting force,the rating is 38.7±5.4,the unit is kN.
