SL1714

Features: · Single chip system for wideband quadrature downconversion· Compatible with all standard high IF frequencies· Excellent gain and phase match up to 30MHz baseband·High output referred linearity for low distortion and multi channel application· Simple low component application· Fully bala...

product image

SL1714 Picture
See larger image
SeekIC No. : 004492452 Detail

SL1714: Features: · Single chip system for wideband quadrature downconversion· Compatible with all standard high IF frequencies· Excellent gain and phase match up to 30MHz baseband·High output referred line...

SL1714 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SL1714
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Single chip system for wideband quadrature downconversion
· Compatible with all standard high IF frequencies
· Excellent gain and phase match up to 30MHz baseband
·High output referred linearity for low distortion and multi channel application
· Simple low component application
· Fully balanced low radiation design with fully integrated quadrature generation
· High operating input sensitivity
· On-board AGC facility
· On chip oscillator for varactor tuning or SAW resonator operation
· ESD protection (Normal ESD handling procedures should be observed)


Application

·Satellite receiver systems
· Data communications systems
· Cable systems


Pinout

Connection Diagram


Specifications

Characteristics Min Max Units Conditions
Supply voltage, Vcc -0.3 7 V
IFFIN &IFINB input voltage   2.5 Vp-p
IFIN & IFINB input DC offset -0.3 Vcc+0.3 V
IOUT & QOUT DC offset -0.3 Vcc+0.3 V
AGC DC offset -0.3 Vcc+0.3 V
VCO1 & 2 DC offset -0.3 Vcc+0.3 V
VCODDIS DC offset -0.3 Vcc+0.3 V
PSCAL & PSCALB DC offset -0.3 Vcc+0.3 V
Storage temperature -55 125 °C
Junction temperature   150 °C
MP16 package thermal resistance
chip to Ambient		   81 °C/W
MH16 package thermal resistance
chip to Ambient		   60 °C/W
MP16 package thermal resistance
chip to case		   28 °C/W
Power consumption at 5.25V   656 mW
