SL2150F

• Single chip quadruple power splitter (primary channel, secondary channel, OOB channel and loop through)
• Wide dynamic range on all channels
• Independent AGC facility incorporated into all channel paths
• CSO, CTB, CXM all better than -62dBc for +3dBmV agc attack point
• Full ESD protection. (Normal ESD handling procedures should be observed)

• Multi-tuner cable set top box and cable modem applications
• Data communications systems
• Terrestrial TV tuner loop though

The SL2150F is a wide dynamic range single chip power splitter for cable set top box multi-tuner applications.
The device offers four buffered outputs from a single input.

All signal paths of SL2150F contain an independently controllable AGC facility.
