SL32-T1

The SL32-T1 is designed as one kind of 3.0A low VF surface mount schottky barrier rectifiers.

It has eight features of the SL32-T1. (1)Its schottky barrier chip. (2)Ideally suited for automatic assembly. (3)Low power loss, high efficiency. (4)Surge overload rating to 100A peak. (5)For use in low voltage application. (6)Guard ring die construction. (7)Plastic case material has UL flammability classification rating 94V-O. Those are all the main features.

Some absolute maximum ratings and electrical characteristics of the SL32-T1 have been concluded into several points as follow. (1)Its peak repetitive reverse voltage would be 20V. (2)Its working peak reverse voltage would be 20V. (3)Its DC blocking voltage would be 20V. (4)Its RMS reverse voltage would be 14V. (5)Its average rectified output current at Tl=75°C would be 3.0A. (6)Its non-repetitive peak forward surge current 8.3ms single half sine-wave superimposed on rated load (JEDEC method) would be 100A. (7)Its forward voltage at If=3.0A would be 0.38V. (8)Its peak reverse current at rated DC blocking voltage would be 0.5mA at Ta=25°C and would be 20mA at Ta=100°C. (9)Its typical thermal resistance junction to ambient would be 55K/W. (10)Its operating temperature range would be from -65°C to 125°C. (11)Its storage temperature range would be from -65°C to 150°C. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to device.

Also some mechanical specifications of the SL32-T1 are concluded as follow. (1)Its case would be low profile molded plastic. (2)Its terminals would be solder plated, solderable per MIL-STD-750, method 2026. (3)Its polarity would be cathode band or cathode notch. (4)Its weight 0.21 grams approx. And so on. At present we have not got so much information about this IC and we would try hard to get more information about it. If you have any question or suggestion or want to know more information please contact us for details. Thank you!
