SL4051B

Features: · Operating Voltage Range: 3.0 to 18 V· Maximum input current of 1 mA at 18 V over full packagetemperature range; 100 nA at 18 V and 25°C· Noise margin (over full package temperature range):-1.0 V min @ 5.0 V supply-2.0 V min @ 10.0 V supply-2.5 V min @ 15.0 V supplyPinoutSpecifications ...

product image

SL4051B Picture
See larger image
SeekIC No. : 004492548 Detail

SL4051B: Features: · Operating Voltage Range: 3.0 to 18 V· Maximum input current of 1 mA at 18 V over full packagetemperature range; 100 nA at 18 V and 25°C· Noise margin (over full package temperature range...

SL4051B Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SL4051B
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·  Operating Voltage Range: 3.0 to 18 V
·  Maximum input current of 1 mA at 18 V over full packagetemperature range; 100 nA at 18 V and 25°C
·  Noise margin (over full package temperature range):
-1.0 V min @ 5.0 V supply
-2.0 V min @ 10.0 V supply
-2.5 V min @ 15.0 V supply


Pinout

Connection Diagram


Specifications

Symbol Parameter
Value
Unit
VCC DC Supply Voltage (Referenced to GND)
-0.5 to +20
V
VIN DC Input Voltage (Referenced to GND)
-0.5 to VCC +0.5
V
VOUT DC Output Voltage (Referenced to GND)
-0.5 to VCC +0.5
V
IIN DC Input Current, per Pin
±10
mA
PD Power Dissipation in Still Air, Plastic DIP+
SOIC Package+
750
500
mW
PD Power Dissipation per Output Transistor
100
mW
Tstg Storage Temperature
-65 to +150
°C
TL Lead Temperature, 1 mm from Case for 10 Seconds
(Plastic DIP or SOIC Package)
260
°C



Description

The SL4051B analog multiplexer/demultiplexer is digitally controlled analog switches having low ON impedance and very low OFF leakage current. Control of analog signals up to 20V peak-to-peak can be achieved by digital signal amplitudes of 4.5 to 20V (if VCC - GND = 3V, a VCC - VEE of up to 13 V can be controlled; for VCC - VEE level differences above 13V a VCC - GND of at least 4.5V is required).

These multiplexer circuits of the SL4051B dissipate extremely low quiescent power over the full VCC -GND and VCC - VEE supply-voltage ranges, independent of the logic state of the control signals. When a logic "1"is present at the ENABLE input terminal all channels are off.

The SL4051B is a single 8-channel multiplexer having three binary control inputs, A,B and C, and an ENABLE input. The three binary signals select 1 of 8 channels to be turned on, and connect one of the 8 inputs to the output.
