Position: Home  > All Categories> Integrated Circuits (ICs) > SL74HCT244

SL74HCT244

Features: ` TTL/NMOS-Compatible Input Levels` Outputs Directly Interface to CMOS, NMOS, and TTL` Operating Voltage Range: 4.5 to 5.5 V` Low Input Current: 1.0 APinoutSpecifications Symbol Parameter Value Unit VCC DC Supply Voltage (Referenced to GND) -0.5 to +7.0 V ...

product image

SL74HCT244 Picture
See larger image
SeekIC No. : 004492745 Detail

SL74HCT244: Features: ` TTL/NMOS-Compatible Input Levels` Outputs Directly Interface to CMOS, NMOS, and TTL` Operating Voltage Range: 4.5 to 5.5 V` Low Input Current: 1.0 APinoutSpecifications Symbol ...

SL74HCT244 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SL74HCT244
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

`  TTL/NMOS-Compatible Input Levels
`  Outputs Directly Interface to CMOS, NMOS, and TTL
`  Operating Voltage Range: 4.5 to 5.5 V
`  Low Input Current: 1.0 A


Pinout

Connection Diagram


Specifications

Symbol

Parameter

Value

Unit

VCC DC Supply Voltage (Referenced to GND)
-0.5 to +7.0
V
VIN DC Input Voltage (Referenced to GND)
-1.5 to VCC +1.5
V
VOUT DC Output Voltage (Referenced to GND)
-0.5 to VCC +0.5
V
IIN DC Input Current, per Pin
±20
mA
IOUT DC Output Current, per Pin
±35
mA
ICC DC Supply Current, VCC and GND Pins
±75
mA
PD Power Dissipation in Still Air, Plastic DIP+ SOIC Package+
750
500
mW
Tstg Storage Temperature
-65 to +150
°C
TL Lead Temperature, 1 mm from Case for 10 Seconds (Plastic DIP or SOIC Package)
260
°C

*Maximum Ratings are those values beyond which damage to the device may occur. Functional operation should be restricted to the Recommended Operating Conditions. +Derating - Plastic DIP: - 10 mW/°C from 65° to 125°C SOIC Package: : - 7 mW/°C from 65° to 125°C




Description

The SL74HCT244 is identical in pinout to the LS/ALS244. The device may be used as a level converter for interfacing TTL or NMOS outputs to High-Speed CMOS inputs.

The SL74HCT244 is an octal noninverting buffer/line driver/line receiver designed to be used with 3-state memory address drivers, clock drivers, and other bus-oriented systems. The device has non-inverted outputs and two active-low output enables.




Customers Who Bought This Item Also Bought

Margin,quality,low-cost products with low minimum orders. Secure your online payments with SeekIC Buyer Protection.
You may also be interested in :
Integrated Circuits (ICs)
TA8435H
1MB12-140
Power Supplies - External/Internal (Off-Board)
A76L-0300-0077
A5E01231722-F2
Tapes, Adhesives
803
AC452-2
Crystals and Oscillators
WT325BI0030.000000
2SB49
Audio Products
HUC1002
WM-64CT
Soldering, Desoldering, Rework Products
TGK-900M-B
TGK-900M-1.6D
View more
