Purchase SM4001, In-stock SM4001 From SeekIC.

MFG:COMON  Package Cooled:MELF  D/C:08+

SM4001 Product Image

SM4 Series Datasheet download

Five Points

Part Number: SM4001



MFG: COMON

Package Cooled: MELF

D/C: 08+



Urgent Purchase

SM4001 Maximum Ratings

Type
Typ
Repetitive peak reverse voltage
Periodische Spitzensperrspannung
VRRM [V]
Surge peak reverse voltage
Stoßspitzensperrspannung
VRSM [V]
SM 4001
50
50
SM 4002
100
100
SM 4003
200
200
SM 4004
400
400
SM 4005
600
600
SM 4006
800
800
SM 4007
1000
1000
SM 513
1300
1300
SM 516
1600
1600
SM 518
1800
1800
SM 2000
2000
2000

Max. average forward rectified current, R-load            TT = 75          IFAV     1 A
Dauergrenzstrom in Einwegschaltung mit R-Last         TT = 100        IFAV     0.8 A
Repetitive peak forward current f > 15 Hz                                            IFRM    10 A 1)
Periodischer Spitzenstrom
Peak forward surge current, 50 Hz half sine-wave       TA = 25         IFSM      40 A
Stoßstrom für eine 50 Hz Sinus-Halbwelle
Rating for fusing - Grenzlastintegral t < 10 ms             TA = 25          i2t          8 A2s
Peak forward pulse current t = 1ms                             TA = 85          IFSM       100 A
Max. zulässiger Stromimpuls
Operating junction temperature - Sperrschichttemperatur                     Tj      - 50...+175
Storage temperature - Lagerungstemperatur                                        TS     - 50...+175
