MFG:SHMC Package Cooled:DIP/18
MFG: SHMC
Package Cooled: DIP/18
Description: SM5028RF is a RF remote control encoder paired with SM5038RF. It utilizes CMOS technology. The chip ha...
SM5028RF is a RF remote control encoder paired with SM5038RF. It utilizes CMOS technology. The chip has 12 bits of 2-state address pins that provides 212 codes. SM5028RF/SM5038RF pair is suitable for use on remote controller.
| Parameter | Symbol | Test conditions |
Ratings |
Unit |
| Supply Voltage | VDD-VSS |
-0.3~13 |
V | |
| Input Voltage | VI-VSS |
VSS-0.3~VDD+0.3 |
V | |
| Output Voltage | Vo-VSS |
VSS-0.3~VDD+0.3 |
V | |
| Maximum Power Consumption | Pa | VDD-VSS=5V |
500 |
mW |
| Operating Temperature | Topr |
-20~70 |
||
| Storage Temperature | Tstg |
-40~125 |
SM5028RF
PDF/DataSheet Download
