Part Number: SM7346





Package Cooled: 2000



Description: The SM7346 is 6 channels electronic volume controlled by 3-wire serial data. The IC is suitable for us...


Urgent Purchase

SM7346 General Description


The SM7346 is 6 channels electronic volume controlled by 3-wire serial data. The IC is suitable for use in DVD systems and AV.

SM7346 Maximum Ratings

Symbol Parameter Conditions
Ratings
Unit
Vsupply Supply Voltage AVDD-AVSS
16.0
V
Pd Power dissipation Ta25
1000
mW
K Thermal derating Ta>25
*standard board
10
mW/
Topr Operating temperature
-20~+75
Tstg Storage temperature
-40~+125
<

SM7346 Features

 ` 4 Output ports
 ` Built-in microcomputer interface circuit controlled by 16-bit serial data.
 ` Electronic volume Volume level: 0dB~-79dB, - dB(1dB/step)
 ` Tone control Bass/Treble, 0dB~+10dB(2dB/step)

SM7346 Typical Application

 ·DVD
·Home Audio Equipment
·AV

SM7346 Connection Diagram

SM7346  Connection Diagram

SM7346 datasheet

SM7346
PDF/DataSheet Download

  • Datasheet: SM7346
  • File Size: 309769 KB
  • Manufacturer: SAMHOP [SamHop Microelectronics Corp.]
  • Click here to Download
